Processing Range |
φ3.0-φ150mm
Max Length of Cut-in Mill400mm |
|
Motor |
For Grinding Wheel 37-45kW 4P
For Guiding Wheel 4kW 6P
For Cooling 0.75kW 2P |
|
Spindle Unit |
Spindle Roller Bearing Double Support Type Grinding Wheel
Spindle Roller Bearing Double Support Type Guiding Wheel |
|
Specification of Grinding Wheel |
610×405×304.8mm(Outer Diameter×Width×Bore Diameter) |
|
Specification of Guiding Wheel |
330×405×203.2mm(Outer Diameter×Width×Bore Diameter) |
|
Rotational Speed |
Grinding Wheel1040rpm(MAX.1400rpm)
Linear Speed33m/s(MAX.45m/s)
Stepless Variable-frequency Speed Regulation of Guide Wheel12-200rpm |
|
Electric Control Device |
FANUC Numerical Control System |
|
Power Supply Voltage |
AC380V, Frequency 50Hz |
|
Control Voltage |
AC100V/110V;DC24V |
|
Tilting Angle of Guiding Wheel |
﹢5°-﹣5° |
|
Floor Area |
3050×3100mm(Width×Length) |
|
Machine Tool Weight |
About 8.5t |
